PROPERTIES

Design

Modular (Microscope, Cameras, Light-source, PC with 2 Monitors)

Microscopy mode

Fluorescence, Brightfield

Compatible Slide Formats

All standard and over-sized slides

Slide Capacity

8

Objectives

Up to 7 Objectives (2.5-100x)

FL-Channels

8

Camera

CCD Camera (14-bit, 1.4 Megapixel, Monochrome)
CMOS Camera (8/10-bit, 4.2 Megapixel, Color)

Light Source

VIS-LED
Solid-state Light Engine

Tissue Microarray (TMA)

YES

Image Analysis Software

QUEST Line (Algorithms for tissue detection, area measurement, scattergrams for cells and many more)

Supported Image Formats

TissueFAXS, OME-TIFF, TIFF, JPEG, BMP, PNG

Viewer

Integrated, stand-alone Freeware
